Technical Specification
|
XP1.8 |
XP2.5 |
|
Pixel Pitch (mm)
|
1.8
|
2.57
|
|
LED Type
|
3 in 1 SMD
|
3 in 1 SMD
|
|
Display Dimension (WxH)/(mm)
|
576x1944
|
576x1944
|
|
Display Resolution (WxH)
|
320x1080
|
224x756
|
|
Panel Material
|
Aluminum
|
Aluminum
|
|
Panel Weight (kg)
|
35
|
35
|
|
Brightness (nit)
|
800-1200
|
800-1200
|
|
Refresh Rate (Hz)
|
>1920
|
>1920
|
|
Gray Scale (bit)
|
16
|
16
|
|
Viewing Angle (H/V) (°)
|
160/160
|
160/160
|
|
Controlling
|
USB / HDMI / WIFI / Internet
|
USB / HDMI / WIFI / Internet
|
|
Supported Video Format
|
MP4 and more
|
MP4 and more
|
|
AC Operating Voltage (V)
|
110~220 (±5%）
|
110~220 (±5%）
|
|
Storage Temperature (℃)
|
﹣40~﹢60
|
﹣40~﹢60
|
|
Operating Temperature (℃)
|
﹣20~﹢60
|
﹣20~﹢60
|
|
IP Rating (Front/Rear)
|
IP40/IP21
|
IP40/IP21
|
|
LED Lifetime (H)
|
100000
|
100000
|
|
Certificate
|
CE FCC ETL RoHS
|
CE FCC ETL RoHS
|
